LUMIMAX® Lighting for the standard-compliant reading and verification of codes

Verification and standard-compliant reading is not only used to decipher codes according to standardised processes but also to measure the quality of the code and assess how it can be analysed. To execute the reading and verification process in line with the standards, the lighting situation is determined alongside camera and software factors. A standard-compliant set-up mostly requires a 90° viewing angle for the camera and thus the camera must be positioned vertically to the test piece.

We would be glad to advise you in detail on this topic. Please contact us personally via our contact form, e-mail Lumimax.Sales(.a-t.)iimAG.de or via telephone +49 3681 / 45519-0.

You can find more information about the topic "lighting for standard-compliant reading and verification of codes" here:

Overview of all suitable lightings:

Model Measurements
Light field (mm):
Operation mode
Continuous Flash
Illumination colours
Red White Blue Green IR UV
To the product configurator
LED Dome Lights
DOM CD50 Diameter
outer: 50
inner: 85
      To the configurator of the Dome Lights
DOM CD50FL Diameter
outer: 50
inner: 85

DOM CD100 Diameter
outer: 160
inner: 100

DOM CD100FL Diameter
outer: 160
inner: 100

DOM CD150 Diameter
outer: 221
inner: 150

DOM CD150FL Diameter
outer: 221
inner: 150

LED Coaxial Lights
LES40 40 x 40       To the configurator of the Coaxial Lights
LES40FL 40 x 40
LES60 60 x 60
LES60FL 60 x 60
LES80 80 x 80
LES80FL 80 x 80
LES100 100 x 100
LES100FL 100 x 100
LES160 160 x 160
LES160FL 160 x 160
LED Bar Lights
LSB50 50 x 20     To the configurator of the Bar Lights
LSB50FL 50 x 20
LSB100 100 x 20
LSB100FL 100 x 20
LSB150 150 x 20
LSB150FL 150 x 20
LSB200 200 x 20
LSB200FL 200 x 20
LB125 125 x 42
LB125FL 125 x 42
LB250 250 x 42
LB250FL 250 x 42
The LED Area Lights of the LG, LQ(HP) and BF series, the LED Spots 3W and 5W as well as the LED Ring Lights of the LR and LSR series can also be used. Therefor, please contact our service team.



Overview of the Mounting Solutions for standard-compliant reading and verfication of codes:

Model Description Suitable for...
Mounting system for
1 Bar Light of the LSB series
  • defined fixing points for standardcompliant 30° and 45° setting
  • adjustable gradual light guidance from bright to dark field
  • LSB50/ 50FL
  • LSB100/ 100FL
  • LSB150/ 150FL
  • LSB200/ 200FL
Mounting system for
4 Bar Lights of the LSB series
  • four-sided mounting bracket for 4 Mini Bar Lights ofthe LSB series
  • defined fixing points for standardcompliant 30° and 45° setting
  • adjustable gradual light guidance from bright to dark field
  • LSB50/ 50FL
  • LSB100/ 100FL
  • LSB150/ 150FL
  • LSB200/ 200FL
Mounting plate
MP-LVA-DOM CD100
  • Mounting plate for Dome Light DOM CD100
  • direct mounting of the Dome Light to LUMIMAX® verification adapter
  • DOM CD100/ 100FL
  • Suitable for the following LUMIMAX® accessories:
    LVA-MV440, LVA-MV5x, LVA-IS5x, LVA-DM36x, LVA-VeriSens XC, LVA-SR1000 SR2000
Mounting bracket
MW-LVA-MS4-LSB50
  • Mounting bracket for LSB50/ 50FL Mini Bar Lights in a four-sided mounting bracket
  • direct mounting of the mounting system MS4 to LUMIMAX® verification adapter
  • LSB50/ 50FL
  • Suitable for the following LUMIMAX® accessories
    LVA-MV440, LVA-MV5x, LVA-IS5x, LVA-DM36x, LVA-VeriSens XC, MS4 (LSB50/ 50FL), LVA-SR1000 SR2000
Mounting bracket
MW-LVA-MS4-LSB100
  • Mounting bracket for LSB100/ 100FL Mini Bar Lights in a four-sided mounting bracket
  • direct mounting of the mounting system MS4 to LUMIMAX® verification adapter
  • LSB100/ 100FL
  • Suitable for the following LUMIMAX® accessories
    LVA-MV440, LVA-MV5x, LVA-IS5x, LVA-DM36x, LVA-VeriSens XC, MS4 (LSB100/ 100FL), LVA-SR1000 SR2000
Verification adapter
  • LSB50/ 50FL
  • LSB100/ 100FL
  • DOM CD50/ 50FL
  • DOM CD100/ 100FL
  • LES40/ 40FL
  • LES60/ 60FL
